Valves

For inquries and quotes, contact us here:
Click here for valve ordering guide:

Janus Control Valves

A patented range of manifold zone valves manufactured in 316 stainless steel for use within the high pressure water mist industry.

Janus Manifolds

Available in 1 to 4 stations including with or without additional relief valve porting and produced in 316 stainless steel

Janus Pressure Compensated Flow Control

The pressure compensated flow control valve is designed to control the flow rate of tap drinking water in a hydraulic system

Janus Hose Burst Valves

Manufactured from 316 stainless steel and special engineering polymer selected for their corrosion resistance and resilience to flow erosion.

Janus DN16 Directional Valves

Actuation by water, oil or compressed air pilot is possible on all configurations.  The water version is also available with an integral DN3 solenoid operated pilot valve.

Janus 4/3 Manual Valve

A patented range of valves  which control the directional flow of corrosive fluids in hydraulic systems.  Designed for operation on tap water.

Actuation Cards

Actuation cards must be used in conjunction with direct acting directional valves for minimum coil size and maximum force.

Electric Flow Control

A patented design of control valves. Available in DN3 and DN6

0-30 l/min

Proprotional Pressure Control

A patented design of control valves.

Between 0-100 l/min the direct acting valve can control system pressure electronically up to 160 Bar.

Intelligent Control

An integrated controller configured to offer open loop, closed loop or human interface control of the electronic pressure and flow control valves.

Directional 4-2 / 3-2

A patented design of control valves. Available in DN6 & DN9 direct acting for flow rates up to 50 l/min. Also available DN16 in pilot actuation versions. Max pressure rating 160 Bar.

Directional 4-3

A patented design of control valves. Available in DN6 & DN9 direct acting for flow rates up to 50 l/min. Also available DN16 in pilot actuation versions. Max pressure rating 160 Bar. Actuation via solenoid, manual, pilot, air or fluid is also available.

Pilot Operated Check Valve

Either mounted directly onto the directional control valve or remotely with porting block. The valve offers 100% seal for load or pressure holding applications.

Direct Acting 2-2

Direct acting at DN3. Available in normally open and normally closed, the valves offer 100% seal that therefore can be used in load holding applications. Also used as the pilot section for DN9 and DN16 on/ off valves. A full range of 2-2 valves up to 100 l/min are 160 bar can be offered.

Priority Flow

Manufactured in all 316 stainless steel and polymer, the valves offer free flow in one direction with a fine accurate metered flow in the reverse. Available in DN3 and DN6 0.5 to 30 l/min at 160 bar can be controlled.

Pressure Control

Available in DN6, DN12 & DN16, flow rates up to 400 l/min. System pressures up to 160 bar can be accurately controlled with this patented pressure control valve.

Check Valves

A unique range of valves that are supplied in 316 stainless steel and high grade engineering polymer as standard.



Available in 3 sizes DN6, DN12 and DN19 100% leak free operation is guaranteed. The range offers consistent performance even after lengthy periods of inactivity.

Pressure Reducing

A patented range of valves that can control the pressure of corrosive fluids in hydraulic systems.



Designed specifically for fluids with low viscosity the valves offers accurate control with high resistance to flow erosion experienced in pressure control applications.
